PLC-4 Inch Smart Touch Screen
Model No:PLC.TP.04D
PLC-4 Inch Smart Touch Screen, this product operates without requiring a master controller for networking and communicates directly with PLC drivers, functioning similarly to a compact host device. Designed for individual spaces, it supports control of 32 lighting channels and 32 customizable scenes. It also enables system networking by connecting to gateway hosts and PLC master controllers.
Contact Us
Wiring Diagram
Product Features
86-type back box installation
Suports 36 programmable keys
High-definition resolution
Supports bidirectional communication
32bit MCU，powerful functionality
Operation Interface Customization Editing
Simple wiring
Scene control
Timed control
Touch Screen Control
Online program update
RS485 protocol-
YC-BUS protocol
Product Specifications
Operating Voltage
AC220V ±10%，50/60Hz
Standby Power Consumption
≤1.7W
PLC Communication Range
300 meter
PLC Device
supports 128 sub-nodes, configurable into 32 control groups
Dimming Modes
supports single-color and dual-tone dimming
Resolution
480*480
Touch Type
4-inch IPS capacitive touchscreen
Project Download
SD card download
Operating Temperature
-5℃~45℃
Operating Relative Humidity
≤90%
Storage Temperature
-20℃~60℃
Storage Relative Humidity
≤93℃
Dimensions（L*W*H）
87mm*86mm*40mm
Net Weight
≤205g/pcs
Installation Method
standard 86 bottom box mounting
Opening Size (L * W)
60mm*60mm，Bottom box depth is greater than 40mm
Dimension
The touch screen adopts a standard 86-type back box for installation
Software Presentation
4inchtouchpanel1280
4inchtouchpanel1280A
0405dimmermodule1280
configuration software1280720
the underground garage
Product Structure Description
By integrating with an intelligent lighting gateway, local switch control and remote switch control can be achieved. It can also be connected to HOMEASSISTANT.
Application Scenarios
Shenzhen Huayi Design Office Smart Lighting Control System
