(1) Supports APP and ETS configuration of button label content;

(2) Switch function: can be used to switch lighting on and off, with long press, short press, and invert functions;

(3) Dimming function: controls dimming devices, with relative and absolute dimming functions;

(4) Curtain control function: can control curtain opening and closing, projection screen raising and lowering, etc.;

(5) Value transmission: can send values of 1 bit/1 byte size;

(6) Scene control function: can perform 8-bit scene control and call the set scene number;

(7) Shift register: sends values in the form of a shift register;

(8) RGB and RGBW control: can be controlled by long press or short press;

(9) Multiple operation function: can send different values and call different types of functions at the same time during an operation;

(10) Delayed value transmission: can send one value or not send it during the operation, and send another value after a delay;

(11) Logic output function: supports OR, AND, XOR, NOR, and NAND. Logic outputs;

(12) Scene module conversion function, supporting scene group forwarding of up to 8 channels, with each group supporting up to 8 configurable outputs;

(13) LED indicator function, with multiple display states selectable, such as: normally open, normally closed, flashing...

(14) With device backlight master-slave function, it can be used as a master device or slave device as needed;

(15) Status and backlight LEDs have brightness wake-up and delayed extinguishing functions. Wake-up conditions include button press, radar sensing, object triggering, etc.
