1. Switch Output

(1) Independent control for each circuit's lights/loads;

(2) With manual switch control capability;

(3) With relay magnetic latching function;

(4) Delayed on/off operation;

(5) Timing off and cyclic on/off;

(6) Status value query and response functionality;

(7) Scene combination control and scene learning capabilities;

(8) Interlock group and channel lock features;

(9) "AND" and "OR" logic operation capabilities;

(10) Selectable relay state after bus power-off and recovery;

(11) I/O dry contact input interface supporting switch, curtain, dimming,

and scene commands, with direct linkage to fire emergency lighting.

2. Curtain Output

(1) Can move up/down, stop/adjust the louvers, change position, etc.

(2) Supports both Blind and Shutter operation modes;

(3) With manual switch control capability;

(4) With relay magnetic latching function;

(5) Status value query and response functionality;

(6) Configurable scene combination control;

(7) Selectable relay state after bus voltage recovery;

(8) I/O dry contact input interface supporting switch, curtain, dimming,

and scene commands, with direct linkage to fire emergency lighting;

(9) Applications: opening and closing curtains, projection screens,

venetian blinds, rolling shutters, lifters, etc.

3. Fan Coil Output

(1) Controls 2-pipe or 4-pipe fan coil output;

(2) Supports fans with 1-speed, 2-speed, and 3-speed control;

(3) Fan operation modes: Auto and Manual;

(4) With manual switch control capability;

(5) With relay magnetic latching function;

(6) Delayed fan on/off function;

(7) Status value query and response functionality;

(8) Selectable relay switch state after bus voltage recovery;

(9) Reports local fan speed and valve status;
