(1) Switch function, which can be used to switch lighting, with long press,short press and inversion functions;

(2) Dimming function, which controls the dimming device, with relative dimming and absolute dimming function output;

(3) Curtain control function, which can control the opening and closing of curtains, the lifting and lowering of projection screens, etc.;

(4) Value sending, which can send 1bit/1byte value;

(5) Scene control function, which can perform 8bit scene control and call the set scene number;

(6) Shift register, which sends values in the form of shift register;

(7) RGB and RGBW control, which can be controlled by long press or short press;

(8) Multiple operation function, which can send different values at the same time and call different types of functions in one operation;

(9) Delayed value sending, which sends a value or does not send it during operation, and sends another value after a delay;

(10) Logic output function, which supports OR, AND, XOR, NOR and NAND logic outputs;

(11) Scene module conversion function, which supports up to 8-channel scene group forwarding, each group supports up to 8 configurable outputs;

(12) LED indication function, multiple display states can be selected, such as: normally open, normally closed, flashing...

(13) It has the master-slave function of device lighting and can be used as a host device or a slave device according to needs;

(14) The status and backlight LEDs have the functions of brightness wake-up and delayed extinguishing. The wake-up conditions include button pressing, radar sensing, object triggering, etc.
